Standard Incinerator
A multi-purpose, a high-efficiency thermal treatment system designed to process various types of bulky and heavy waste through a controlled batch-loading method. Utilizes advanced pyrolysis gasification to ensure complete decomposition while minimizing environmental impact.
Product Overview
This multipurpose incinerator employs a dual-chamber process where waste is gasified in the primary chamber and completely burned in the secondary chamber to achieve smokeless and odorless operation. It is constructed with high-performance refractory castable materials that withstand extreme temperatures, significantly extending the equipment's lifespan. The design minimizes manual labor by requiring almost no pre-treatment, such as sorting or crushing, of the waste before input. Additionally, an integrated centrifugal dust collector ensures that only clean gases are released through the stack following 3rd stage combustion.
Ideal Applications
Key Capabilities & Features
- Pyrolysis gasification: Decomposes waste while preventing secondary pollution
- Smokeless and odorless: Ensures complete combustion of unburned gases
- Automatic control: Simplifies operation through an automated PLC system
- Minimal fuel consumption: Highly efficient and economically superior design
- No pre-treatment: Eliminates the need for sorting or crushing
- High-temperature refractory: Enhanced durability using special long-lasting materials
- Labor cost reduction: Operates without management staff after batch loading
- Compact installation: Engineered to minimize the required facility footprint
Technical Specifications
Capacity Range
50 - 300 kg/hr
Available Models
| Model No. | Capacity |
|---|---|
| ECOG-50 | 50 kg/h |
| ECOG-100 | 100 kg/h |
| ECOG-150 | 150 kg/h |
| ECOG-200 | 200 kg/h |
| ECOG-300 | 300 kg/h |
